The Dewetron 2010 is a complete Windows-based data acquisition package that is ideally suited for in-vehicle data acquisition. The unit consists of a data acquisition computer, power supply, interchangeable signal condition modules and computer monitor in a single compact package. It is equipped with a daylight-readable windshield-mounted display for immediate driver feedback. Its high channel count and sample rate make it an excellent package for brake performance and NVH data acquisition.

Dewetron 2010 has the following capabilities:

• Wide range of operational voltage — 10 to 30 volts
• AC or DC powered
• Equipped with a HUD for immediate driver feedback
• Wireless Ethernet capability
• Supports a wide range of input types, including:
  • Bridge
  • Encoders
  • ICP
  • LVDT
  • Thermocouples, etc.
• Supports 64 analog, 10 digital and five pulse inputs
• Sample rates up to 50k Hertz with 12-bit ADC
• Supports multiple sample rates
• Excitation can be defined on a per-channel basis
• Capable of performing simultaneous data acquisition and reduction in real time

Data can be provided in other formats such as Excel.

Dewetron VGPS

The Dewetron VGPS is a high-precision GPS sensor suitable for use in measuring vehicle velocity, stopping distance and GPS coordinates. It has both analog and digital outputs for use in conjunction with a data acquisition system such as the Dewetron 2010 or the SoMat eDAQ. It also provides velocity and GPS coordinates in either Dewetron Proprietary or NMEA mode. It features a multifunction HUD to provide instant driver feedback.

Dewetron VGPS has the following capabilities:

• Wide range of operational voltage — 10 to 30 volts
• Zero to 10-volt analog output
• TTL pulse output – 200 pulses per meter
• NMEA compatible serial output
• HUD with speed in mph or kph, heading in degrees, vertical elevation and Greenwich Mean Time (GMT)
• Supports “stand-alone” operation with a laptop computer for off-site route tracking
